Phoenix 1.5 LiveView & PubSub Basics

Create a Dynamic Web GUI without JavaScript!

I have been watching Phoenix and Elixir for a while, and the idea of writing dynamic Web Applications without needing a ton of JavaScript is very interesting. I recently saw this video by Chris McCord:

which is very cool. I wanted to learn more and found this Phoenix 1.4 tutorial:

and decided to translate that into Phoenix 1.5. This is what follows.

NOTE: Since I am just learning the Phoenix Framework and will need to refer to this for my self to remember how to do basic things – I’ve documented every little detail.

Step 0 - setup environment

Setup environment & newest version of elixir:

exenv install 1.10.3
exenv global
exenv local 1.10.3

Install the 1.5.1 phx_new generator:

mix archive.install hex phx_new 1.5.1

Step 1: Create a Phoenix Project with LiveView

Create the project (notice the --live - that enables LiveView, --no-ecto - keeps the project smaller since we won’t be persisting any data):

mix phx.new counter --no-ecto --live

enter project and create init commit:

cd counter
git init && git add -A && git commit -m "init"

Step 2 - simple counter page using LiveView

Make a counter_live folder & an index.ex file:

mkdir lib/counter_web/live/counter_live
touch lib/counter_web/live/counter_live/index.ex

Add the following contents:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
# lib/counter_web/live/counter_live/index.ex
defmodule CounterWeb.CounterLive.Index do
  use CounterWeb, :live_view

  # since we don't have a db to pull from we initialize on mount
  @impl true
  def mount(_params, _session, socket) do
    {:ok, assign(socket, :val, 0)}
  end

  def render(assigns) do
    ~L"""
    <h1>Live Counter</h1>
    <p>
      <b>Here is a great complex page</b>
    </p>

    <div>
      <h2>The count is: <%= @val %></h2>
      <button phx-click="dec">-</button>
      <button phx-click="inc">+</button>
    </div>
    <div>
      <button phx-click="clear">clear</button>
    </div>

    <p>
      <i>even more awesome content</i>
    </p>
    """
  end

  # event handler for <button phx-click="inc">
  def handle_event("inc", _, socket) do
    {:noreply, update(socket, :val, &(&1 + 1))}
  end

  # event handler for <button phx-click="dec">
  def handle_event("dec", _, socket) do
    {:noreply, update(socket, :val, &(&1 - 1))}
  end

  # event handler for <button phx-click="clear">
  def handle_event("clear", _, socket) do
    {:noreply, update(socket, :val, &(&1 - &1))}
    # {:noreply, update(socket, :val, 0)} # very slow - why?
  end

end

Now update the routers (so we can get to the new webpage – now our app should work:

1
2
3
4
5
6
  scope "/", CounterWeb do
    pipe_through :browser

    # live "/", PageLive, :index        # remove this line
    live "/", CounterLive.Index, :index # add this line
  end

Start pheonix:

mix phx.server

Go to:

localhost:4000

You should now see the website and the counter should function

Assuming all is good, I’ll take a git snapshot:

git add .
git commit -m "counter with live update"

Step 3 - Running tests

In order to run the tests we type:

mix test

We see that PageLive test fails. This is because we replaced this behavior with CounterLive

To fix this we will create a CounterLive test and delete PageLive test.

rm test/counter_web/live/page_live_text.exs
touch test/counter_web/live/counter_live_text.exs

Here is the code for our new test: it basically just checks to be sure our Title is on the page:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
# test/counter_web/live/counter_live_text.exs
defmodule CounterWeb.CounterLiveTest do
  use CounterWeb.ConnCase

  import CounterWeb.CounterLive.Index

  test "disconnected and connected render", %{conn: conn} do
    {:ok, page_live, disconnected_html} = live(conn, "/")
    assert disconnected_html =~ "Live Counter"
    assert render(page_live) =~ "Live Counter"
  end

end

Now we can test again: mix test

Now that works, lets take another git snapshot:

git add .
git commit -m "counter with live update"

Step 4 – LiveView Templates

Create a template file (helpful for complex html pages, but simple to create):

touch lib/counter_web/live/counter_live/index.html.leex

Now just copy the html (from the render method into this file):

# lib/counter_web/live/counter_live/index.html.leex
<h1>Live Counter</h1>
<p>
  <b>Here is a great complex page</b>
</p>

<div>
  <h2>The count is: <%= @val %></h2>
  <button phx-click="dec">-</button>
  <button phx-click="inc">+</button>
</div>
<div>
   <button phx-click="clear">clear</button>
</div>

<p>
  <i>even more awesome content</i>
</p>

Now point lib/counter_web/live/counter_live/index.ex to this file by replacing render with an apply command:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
  # add this new function
  defp apply_action(socket, :index, _params) do
    socket
  end
  # remove this funtion
  # def render(assigns) do
  #  ~L"""
  #   ...
  #   """
  # end

NOTE: apply_action understands the rest verbs such as :new, :show etc.

Now try the app again and it should still work!

Assuming it still works, I’ll take another git snapshot:

git add .
git commit -m "counter using a template"

Step 5 - Reusable Components (& isolation)

This allows complex components to be reused within multiple templates and isolation to keep one’s mental scope minimal.

Create a file for the component:

touch lib/counter_web/live/counter_live/counter_component.ex

Move the dynamic html and it’s associated functions into this file, it’s important to import the live_components into this file using:

use CounterWeb, :live_component

In order to encapsulate the events into the component we will also move the event handlers into the component file.

So this file will now look like:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
# lib/counter_web/live/counter_live/counter_component.ex
defmodule CounterWeb.CounterLive.CounterComponent do
  use CounterWeb, :live_component

  def render(assigns) do
    ~L"""
    <div>
      <h2>The count is: <%= @val %></h2>
      <button phx-click="dec" phx-target="<%= @myself %>">-</button>
      <button phx-click="inc" phx-target="<%= @myself %>">+</button>
    </div>
    <div>
      <button phx-click="clear" phx-target="<%= @myself %>">clear</button>
    </div>
    """
  end

  def handle_event("inc", _, socket) do
    {:noreply, update(socket, :val, &(&1 + 1))}
  end

  def handle_event("dec", _, socket) do
    {:noreply, update(socket, :val, &(&1 - 1))}
  end

  def handle_event("clear", _, socket) do
    # {:noreply, update(socket, :val, 0)} # very slow - why?
    {:noreply, update(socket, :val, &(&1 - &1))}
  end

end

Notice the button tags are slightly more complex

<button phx-click="dec" phx-target="<%= @myself %>">

the @myself basically informs the event that the handler is within the component.

Now update the live template to point at the component using:

<%= live_component @socket, CounterWeb.CounterLive.CounterComponent, id: 0, val: @val %>

Also note we need to pass the @val value into the component using:

id: 0, val: @val

its a little wierd, but we need to pass an id even if there is no ecto backed record.

Now the template file looks like a normal template file again (focused on formating):

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
# lib/counter_web/live/counter_live/index.ex
defmodule CounterWeb.CounterLive.Index do
  use CounterWeb, :live_view

  # since we don't have a db to pull from we initialize on mount
  @impl true
  def mount(_params, _session, socket) do
    {:ok, assign(socket, :val, 0)}
  end

  def render(assigns) do
    ~L"""
    <h1>Live Counter</h1>
    <p>
      <b>Here is a great complex page</b>
    </p>

    <%= live_component @socket, CounterWeb.CounterLive.CounterComponent, id: 0, val: @val %>

    <p>
      <i>even more awesome content</i>
    </p>
    """
  end

end

Lets check that this still works.

Assuming it still works, I’ll make one last git snapshot:

git add .
git commit -m "live pages using isolated components - like JS does"
